Renogy 12V 200Ah Core Series LiFePO4 Battery
Your trusted, one-stop upgrade from lead-acid to 200Ah lithium is here.

200Ah Core vs. Lead-acid
Upgrade to lithium for the next-level performance

200Ah Core vs. Other LiFePO4
Unparalled performance for demanding energy needs


Extra Juice. More Possibilities.
Renogy 12V 200Ah Core delivers more than you imagine. Get max. 6% more capacity to brace for the unexpected storms, hurricane, wildfire, and other challenges whenever you need.
Powerful to the Core
Offering you consistent power that is almost 10 times longer than an average lead-acid battery, Renogy 12V 200Ah Core LiFePO4 Battery features ev-grade battery cells to ensure lasting performance.

Year-round Protections
The built-in 200A battery management system (BMS) brings you peace of mind for all-year-round use. The low-temperature cut off actively prevents your battery from charging when the mercury plunges below 32°F.

Dimensional Reference Guide
Before installing the battery, please note that you need to leave 5-10 cm (1.97-3.94 in) for the top of the battery; the side with busbars needs to be left at least 20 cm (7.87 in).

The Renogy Difference
Going solar is not that complicated. Renogy is here to help you build your system faster so you can roam further.

10+ Years' Expertise in Off-Grid Power Solutions

Local Warehouses in AU

5-Year Warranty

24-Hour Prompt Response
Find the Power That Is Right for You


CORE SERIES - 12V 200AH DEEP CYCLE LITHIUM IRON PHOSPHATE BATTERY
ELECTRICAL SPECIFICATIONS
Rated Capacity: 200Ah
Nominal Voltage: 12.8V
Energy: 2560Wh
Cycle Life (0.5C/1C, 25℃): 5000 Cycles (80% DOD, 80% EOL)
TEMPERATURE PARAMETERS
Operation Temperature Range: Charge: 0°C to 55°C / 32°F to 131°F
Operation Temperature Range: Discharge: -20°C to 60°C / -4°F to 140°F
Storage Temperature Range: -25°C to 65°C / -13°F to 149°F
Operation Relative Humidity: 10% to 95%
CHARGING PARAMETERS
Charge Voltage: 14.4V
Maximum Continuous Charge Current: 100A
DISCHARGING PARAMETERS
Maximum Continuous Discharge Current: 200A
Peak Discharge Current: 400A@10s
MECHANICAL SPECIFICATIONS
Dimension (L x W x H): 522 x 240 x 219 mm / 20.55 x 9.45 x 8.62 in
Weight: 21.45 kg / 47.3 lbs
Terminal Bolt Size: M8 x 1.25 x 15 mm
Protection Rating: IP65
CERTIFICATIONS
MSDS, UN38.3, FCC, PSE, CE, UKCA: YES
WARRANTY
5-year warranty
